    Flex OBD for MT05, MT05.2, and MT05.3

    New Flex solution for two wheels and quads

    Download the latest version of the Flex software to program two-wheel vehicles and quads in OBD.

    With this new release, Delphi MT05, MT05.2, and MT05.3 control units are now supported, specifically those installed on a wide range of motorcycles branded Benelli, CF Moto, QJ Motor, SWM Motorcycles, and many more.

    The new OBD protocol allows full read of the Flash memory and to write the map area via the diagnostic socket of the vehicle or connections to the connector.

    Moreover, thanks to the Recovery via HW function, the ECU can now be restored even in complex situations, such as in case a corrupted or unsuitable file has been written on the engine unit: this feature automatically activates in case of connection errors.

    Some of the supported vehicles:

    • Benelli 752S 75PS
    • Benelli BN600 86PS
    • CF Moto CForce 850XC 65PS
    • QJ Motor Flash 300S 31PS
    • SWM Motorcycles 500R 35PS


    This new protocol is available for the following software packages:
    OBD

    • FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
    • FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
    • FLS0.5M – SW Flex Full Master
    • FLS0.5S – SW Flex Full Slave
    • FLS0.13M – SW Flex Bikes OBD/Bench/Boot Master
    • FLS0.13S – SW Flex Bikes OBD/Bench/Boot Slave



    Newly added protocols:
    (OBD)

    • All Delphi MT05 C164CM (KWP) Read Internal Flash, Write/Checksum Calculation Maps
    • All Delphi MT05.2 C164CS (KWP) Read Internal Flash, Write/Checksum Calculation Maps
    • All Delphi MT05.3 SPC572L (UDS) Read Internal Flash, Write/Checksum Calculation Maps

    Reading Time : ~ 1 minute  Writing Time : ~ 20 seconds


    Bug fixes:

    • Fixed CRC type on FCA Marelli MM10JA

    Click here to discover the full list of supported vehicles.
