Bench and Boot Programming for Industrial Vehicles with Flex Support for Scania Bosch EGC4.0
With the newly released 7.24.0.0 version of Flex, new supports have been added for industrial vehicles: you can now program the Bosch EGC4.0 control module in Bench and Boot modes thanks to the Flex Support for Scania Bosch EGC4.0.
As of today, you can work on Scania and MAN vehicles running on methane gas (CNG), accessing the whole content of their ECM Flash and EEPROM memories.
Not just engine performance calibration and optimization, but also control module restoring and cloning procedures in an easy and safe way: just read the full backup of the damaged module and transfer it on the working ECM to complete the replacement.
Some of the supported vehicles:
- Scania Trucks Series G340 12.7L 410PS
- Scania Trucks Series R410 12.7L 410PS
- MAN Bus Lion’s City A26 12.8L 310PS
This new protocol is available for the following software packages:
Bench
- FLS0.5M – SW Flex Full Master
- FLS0.5S – SW Flex Full Slave
- FLS0.15M – SW Flex Heavy Duty OBD/Bench/Boot Master
- FLS0.15S – SW Flex Heavy Duty OBD/Bench/Boot Slave
Boot
- FLS0.5M – SW Flex Full Master
- FLS0.5S – SW Flex Full Slave
- FLS0.10M – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Master
- FLS0.10S – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Slave
- FLS0.15M – SW Flex Heavy Duty OBD/Bench/Boot Master
- FLS0.15S – SW Flex Heavy Duty OBD/Bench/Boot Slave
Newly added protocols:
(Bench)
- Scania Trucks Bosch EGC4.0 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write/Checksum Calculation Internal EEPROM, Read/Write External EEPROM, Full Backup
Reading Time : ~ 1 minute Writing Time : ~ 1 minutes
(Boot)
- Scania Trucks Bosch EGC4.0 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write/Checksum Calculation Internal EEPROM, Read/Write External EEPROM, Full Backup
Reading Time : ~ 1 minute Writing Time : ~ 40 seconds
Bug fixes:
- Added new CRC support for PSA Vitesco GPEC4LM
- Added new CRC types for All Cummins CM2350A
- Added new CRC type for All Cummins CM2350B
- Added new CRC type for All Cummins CM2880
- Added new CRC type for Mercedes Trucks/Buses Continental ACM2.1
- Added new CRC type for Mitsubishi Fuso Continental MCM2.1
- Added new CRC type for Mazda Denso S8xx
- Added new CRC type for VAG Temic DQ200G2.1
- Added new CRC type for Ducati Continental M4C
- Added new CRC type for Ford Bosch MG1CS036
- Added new CRC type for Ford Delphi MPC555
- Fixed CRC detection in MT05.3
- Fixed some CRC versions of VAG Bosch EDC17CP44
