Version 6.54.0.0 of Flex out now
Program the latest MED17.8.10.1 with TC1782F processors in Bench or Boot mode.
With this new release of Flex you will be able to work on the newest MG vehicles, accessing the full content of Internal Flash and Internal EEPROM memories.
Moreover, you will have the possibility to restore the unit in case of damage: just write the content of the vehicle ECU on another working and compatible unit.
Some of the supported vehicles:
- MG EHS 1.5L T-GDI 162PS Hybrid
- MG HS 1.5L T-GDI 220PS Hybrid
- Saic MG 6 1.5L T-GDI 169PS Hybrid
This new protocol is available for the following software packages:
Bench
- FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
- FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
- FLS0.5M – SW Flex Full Master
- FLS0.5M – SW Flex Full Slave
- FLS0.10M – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Master
- FLS0.10S – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Slave
Boot
- FLS0.5M – SW Flex Full Master
- FLS0.5M – SW Flex Full Slave
- FLS0.10M – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Master
- FLS0.10S – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Slave
Newly added protocols:
(Bench)
- MG Bosch MED17.8.10.1 TC1782F Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup/Clone
Reading Time: ~ 2 minutes Writing Time: ~ 1.30 minute
(Boot)
- MG Bosch MED17.8.10.1 TC1782F Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup/Clone
Reading Time: ~ 2 minutes Writing Time: ~ 1.30 minute
Bug fixes:
- Added new CRC type for Renault Hitachi BED501
- Added new CRC type for All Continental M3C
- Added new CRC type for FCA Marelli MM10JA
- Added new CRC type for Mercedes Continental AMC2.1
- Added new CRC type for SPL Continental SID605 (Zoomlion)
- Added new CRC type for VAG Continental Simos18.4
- Fixed CRC calculation on Ford Bosch MG1CS017, MG1CS018 and MG1CS019
Software improvements
- Added support for a new version of VAG Continental DL800
