MD1 and MG1 VAG by OBD: it’s now possible
MAGICMOTORSPORT has just released new OBD protocols for MD1 and MG1 ECUs used on VAG group cars in FLEX version 3.14.0.0, allowing you to work on these units quickly and easily.
Test Example: Audi Q7 Quattro Etron – ECU MD1CP004, writing time about 2 min.
All “stages” are completed effortlessly and quickly by OBD.
These solutions for MD1 and MG1 VAG control units provided by MMS can also be recalibrated directly via OBD.
The VAG OBD protocol is one of the most anticipated protocols in the industry, with FLEX today it is a reality!
Supported VAG group cars: Audi, VW, Seat, Lamborghini, Porsche, Skoda.
New protocols added:
- Audi Bosch MD1CP004 OBD: Write/Checksum Maps (requires TPROT OFF in bench mode before)
- Audi Bosch MD1CP014 OBD: Write/Checksum Maps (requires TPROT OFF in bench mode before)
- Audi Bosch MG1CS011 OBD: Write/Checksum Maps (requires TPROT OFF in bench mode before)
- Audi Continental Simos 8.6 OBD: Read/Write/Checksum Maps (needs Unlock in boot mode before writing MOD)
- Audi Continental Simos 8.6 Boot: Read/Write/Unlock External EEPROM
- Chery Marelli 9GC Boot: Read/Write/Checksum Internal Flash, Read/Write External EEPROM 95640, Full Read/Full Write Clone/Restore
- Chevrolet Siemens SIM2K-D160 MPC562 BDM: Read/Write/Checksum External Flash S29CD016G
- Citroen Delphi DCM6.2A OBD: Read/Write/Checksum Maps
- Citroen Valeo V46.11 OBD: Read/Write/Checksum Maps
- Cowim Marelli 9GC Boot: Read/Write/Checksum Internal Flash, Read/Write External EEPROM 95640, Full Read/Full Write Clone/Restore
- DS Delphi DCM6.2A OBD: Read/Write/Checksum Maps
- Opel Delphi DCM6.2A OBD: Read/Write/Checksum Maps
- Peugeot Delphi DCM6.2A OBD: Read/Write/Checksum Maps
- Peugeot Valeo V46.11 OBD: Read/Write/Checksum Maps
- Seat Bosch MG1CS011 OBD: Write/Checksum Maps (requires TPROT OFF in bench mode before)
- Toyota Delphi DCM6.2A OBD: Read/Write/Checksum Maps
- Vauxhall Delphi DCM6.2A OBD: Read/Write/Checksum Maps
- Volkswagen (VW) Bosch MG1CS011 OBD: Write/Checksum Maps (requires TPROT OFF in bench mode before)
Software improvements:
- VAG Bosch MD1 & MG1 Bench: added reversible TPROT OFF function, which allows the user to write the vehicle in OBD any amount of times. If this procedure is not done initially, it will not be possible to write files by OBD.
You can click here to review the full list of vehicles supported by FLEX.
